Carton Box Partition Assembler Machine Clapboard Partition Machine
Used for cardboard partition making
< border="0" ori-width="750" ori-height="306" />
| Name | Unit | Data |
| Horizontal inserting width: A | mm | 120~900 |
| Lengthways sheets length: B | mm | 210~450 |
| Clapboard Height: C | mm | 85~300 |
| Lengthways clapboard distance: D | mm | 20~400 |
| Horizontal clapboard distance: E | mm | 45-850 |
| Lengthways sheets No. | PCS | 1-6 |
| Horizontal clapboard No. | PCS | 1-21 |
| Carton inserting mouth width:F | mm | ＞board thickness |
| Carton thickness:G | mm | 1.5~8mm |
Product Application
automatic partition assembler machine is optimized to be a new partition assembler devices on the basis of absorbing the advantage of equipment at home and abroad in our factory.
The equipment takes the place of the traditional manual operation made, automatic complete insertion of clapboard, saving labor costs, effectively improve the production efficiency at the same time.
It is the ideal packing equipment of fruit and vegetable, glass ceramic, plastic and so on.
Main Feature:
1. Suitable for the auto insertion of all kinds of carton clapboard Clapboard Partition Machine.
2. Vertical direct using vacuum adsorption feeding, landscape orientation using servo feeding , quick and accurate Clapboard Partition Machine.
3. Longitudinal and transverse to cross the two pieces of paper at the same time Clapboard Partition Machine.
4. Longitudinal feeding shaft adopts electric lifting Clapboard Partition Machine.
5. Landscape orientation feeding worktable lifting adopts electric adjustment Clapboard Partition Machine.
6. Electric adjust the clapboard height in landscape orientation Clapboard Partition Machine.
7. Output in double work positions, high efficiency and energy saving Clapboard Partition Machine.
1.Suitable for the auto insertion of all kinds of carton clapboard Clapboard Partition Machine.
2.Vertical direct using vacuum adsorption feeding , landscape orientation using servo feeding , quick and accurate Clapboard Partition Machine.
3.Longitudinal and transverse to cross the two pieces of paper at the same time Clapboard Partition Machine.
4.Longitudinal feeding shaft adopts electric lifting Clapboard Partition Machine.
5.Landscape orientation feeding worktable lifting adopts electric adjustment Clapboard Partition Machine.
6.Electric adjust the clapboard height in landscape orientation Clapboard Partition Machine.
7.Output in double work positions, high efficiency and energy saving Clapboard Partition Machine.
8.Touch screen input control, electric to adjust the clapboard parameters Clapboard Partition Machine.
9.Comprehensive using of pneumatic and electric control, to ensure the advancement of machine control Clapboard Partition Machine.
10.Using compressed air storage tanks for gas centralized supply, gas supply pressure stability, enough gas source.The gas devices get the gas from the primary tracheal , independent control, no influence between each other Clapboard Partition Machine.
11.Equipped with fault detection device, auto stop the machine when paper blocking Clapboard Partition Machine.
